Control Panels HPU-DCO-EFO
Standard HPU
The hydraulic power unit is specially designed for road blockers and barriers. The oil tank capacity is 40 litres. The hydraulic system includes a pressure gauge, manual hand pump, oil level and temperature indicator, directional control valve, filler cap, pressure adjustment system and a 5.5 kW electric motor.
DC Operation (DCO)
In the event of a power failure, the optional DCO system allows 6 to 10 complete operating cycles without mains power. An advanced battery charging circuit ensures seamless transfer between AC and DC power. The system includes a 24 VDC, 2.2 kW DC power unit and two 12 VDC 50 A dry-type maintenance-free batteries. Oil tank capacity is 100 litres.
Emergency Fast Operation (EFO)
The optional Emergency Fast Operation feature uses a high-pressure accumulator to raise the road blocker to the fully deployed position in approximately 1 second. The function is activated via the panic button on the control panel. Oil tank capacity is 100 litres.
Get a Quote
TECHNICAL SPECIFICATIONS
| Panel Dimensions | Width (mm) | Depth (mm) | Height (mm) |
|---|---|---|---|
| STANDARD HPU | 750 | 400 | 1300 |
| DCO | 1250 | 510 | 1320 |
| EFO | 1250 | 510 | 1320 |
| DCO/EFO | 1250 | 510 | 1320 |
They are used in areas requiring high performance and reliability, such as parking lots, industrial facilities, and highway toll booths. Ücret Toplama Sistemleri ve otoyol gişeleri gibi yoğun araç akışının bulunduğu, yüksek hız gerektiren uygulamalar için özel olarak tasarlanmıştır.
